Kidde VS4 - Loop Worksheet

Appendix B: Worksheets
P/N 3102351-EN • REV 005 • ISS 28DEC18 213
CID
Test
Print ☐ Yes ☐ No
NET ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (four-digit coded output)
CID
Loop worksheet
The loop worksheet is used to document your loop settings.
Note: For default settings, see “Factory default settings” on page 42.
Loop class
Loop 1 class ☐ Class B ☐ Class A
Loop 2 class ☐ Class B ☐ Class A
Loop 3 class ☐ Class B ☐ Class A
Loop 4 class ☐ Class B ☐ Class A
Mapping
☐ Disabled ☐ Enabled
Loop 2 enable
☐ Yes ☐ No
Loop 3 enable
☐ Yes ☐ No
Loop
4 enable ☐ Yes ☐ No
