16 TOS7200
Connecting the Test leadwires
Test leadwires connect the product to the DUT.
Connecting to the OUTPUT terminals
Connecting the low voltage side test leadwire
1
Press the STOP switch.
2
Check that the DANGER lamp is off.
3
Check that there is no breakage in the test leadwires.
4
Connect the low voltage side test leadwire to the LOW terminal.
Connecting the high voltage side test leadwire
Perform the following procedure after connecting the low voltage side test leadwire:
1
Press the STOP switch.
2
Confirm that the DANGER lamp is off.
3
Connect the high voltage side test leadwire to the HIGH terminal.
4
Short-circuit the low voltage side and high voltage side test leadwires to
confirm that no high voltage is output.
WARNING
Insecure connection of a test leadwire may cause the entire DUT to be charged to high
voltage, posing a danger. Take care to connect the test leadwires securely.
