TOS7200 53
Specifications
Interface and other functions
REMOTE 6-pin mini-DIN connector on the front panel
The optional remote controller RC01-TOS or RC02-TOS is connected to remotely
control starting/stopping of a test (note that a DIN-mini DIN adapter is required).
SIGNAL I/O D-SUB 25-pin connector on the rear panel
For names and descriptions of connector signals, see Separate Table 3.
Input High-level
input voltage
11 V to 5 V All input signals are active Low controlled.
The input terminal is pulled up to +12 V using a resistor.
Opening the input terminal is equivalent to inputting a
high-level signal.
Low-level
input voltage
0 V to 4 V
Low-level
input current
-5 mA maximum
Input time width 5 ms minimum
Output Output method Open drain output (4.5 Vdc to 30 Vdc)
Output
withstand
voltage
30 Vdc
Output
saturation
voltage
Approx. 0.7 V (25 )
Maximum output
current
400 mA (TOTAL)
ANALOG OUT Outputs a logarithmically compressed voltage corresponding to the measured
resistance value
+
Rx (1 M: 0.30 V, 10 M: 1.04 V, 100 M: 2.00 V, 1000 M: 3.00 V, 10000 M or
more: 4.00 V)
Output impedance: 1 k
COM Analog output-circuit common
Accuracy ± (2% of full scale)
RS232C D-SUB 9-pin connector on the rear panel (compliant with EIA-232-D)
All functions other than the POWER switch and KEYLOCK function are remotely
controllable.
Baud rate 9600/19200/38400 bps
(data: 8 bits; parity: none; stop bit: 2 bits fixed)
Display 7-segment LED, 4-digit voltage display, 4-digit insulation resistance display,
and 3-digit time display
Memory function A maximum of 10 types of test conditions can be stored in memory.
Backup battery life 3 years or more (at 25 °C)
TEST MODE MOMENTARY A test is conducted only when the START switch is pressed.
FAIL MODE Disables cancellation of FAIL judgment using a stop signal via remote control.
DOUBLE ACTION Starts a test only when the STOP switch is pressed and the START switch is pressed
within approximately a half-second.
PASS HOLD Allows the time of holding PASS judgment to be set to 0.2 s or HOLD.
KEYLOCK Places the tester in a state in which no keystroke other than the START/STOP switch
is accepted.
Vo = log
1 +
0ȍ
Rx
Rx: Resistance measurement
(
)
