34 TOS7200
System Setting
Description of each item
Double action (DOUBLE ACTION)
When DOUBLE ACTION is set to ON, the START switch must be pressed within
approximately a half-second after the STOP switch is pressed to start testing. Pressing only
the START switch does not start a test; this function requires pressing both the STOP and
START switches, making the procedure more complicated. Nevertheless, this method
offers greater safety.
When operating the tester through the RS232C interface, set this feature to OFF.
Momentary (MOMENTARY)
When MOMENTARY is set to ON, the tester performs a test only for as long as the START
switch remains pressed.
Since this operation keeps the operator’s hands confined to the front panel of the tester or
the optional remote control box during a test, it increases the safety of operations. Use of
this function together with the optional RC02-TOS (a remote control box operated using
both hands) further increases safety.
When controlling the tester via the RS232C interface, set this feature to OFF.
Fail mode (FAIL MODE)
With FAIL MODE set to ON, a FAIL judgment can only be canceled using the STOP switch
on the front panel. It cannot be cancelled by a stop signal from the remote control.
Pass hold (PASS HOLD)
When PASS HOLD is set to ON, a PASS judgment is held until the STOP switch is pressed.
Average count (AVG)
The number of averaging times is fixed to “100”.
7-segment LED Setting
0 DOUBLE ACTION is OFF
← At initialization
1 DOUBLE ACTION is ON
7-segment LED Setting
0MOMENTARY is OFF
← At initialization
1MOMENTARY is ON
7-segment LED Setting
0 FAIL MODE is OFF
← At initialization
1FAIL MODE is ON
7-segment LED Setting
0PASS HOLD is OFF
← At initialization
1PASS HOLD is ON
7-segment LED Setting
1Number of averaging times: 100(Fixed)
