TOS7200 9
8 System setting display Indicates the selected function when system settings are being
configured.
p. 33
DOUBLE ACTION Indicates the setting for the DOUBLE ACTION function.
1: ON, 0: OFF
p. 34
MOMENTARY Indicates the setting for the MOMENTARY function.
1: ON, 0: OFF
p. 34
FAIL MODE Indicates the setting for the FAIL MODE function.
1: ON, 0: OFF
p. 34
PASS HOLD Indicates the setting for the PASS HOLD function.
1: ON, 0: OFF
p. 34
AVG Shows the number of averaging times. p. 34
AUTO RANGE Shows the measurement range mode.
1: auto-range, 0:fixed range
p. 35
LOWER ON Indicates the lower judgment function
1: ON, 0: OFF
p. 35
SPEED Shows the communication rate for RS232C communications.
0: 9600 bps, 1: 19200 bps, 2: 38400 bps
p. 35
BUZZER Indicates the buzzer volume level (10 levels from 0 to 9) p. 35
9 KEYLOCK LED Lights up when the tester is in KEYLOCK state. p. 37
10
REMOTE LED
*1
Lights up when the tester is remotely controlled through the RS232C
interface.
—
*1. When lit, all inputs except the STOP switch are not accepted. To return to local mode, press LOCAL (SHIFT).
No. Name Description See
