Kimo 210-R Series User Manual

5. F 200: CHANNELS AND MEASUREMENT UNITS
CONFIGURATION
This folder allows to activate the channels and to configure the measurement unit for each channel.
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 8).
➢ Press OK.
➢ Press Up key to go to the folder “F 200”.
➢ Press OK.
“00” blinks and the unit corresponding to the channel 1 is displayed.
➢ Press OK.
The unit blinks.
➢ Press Up and Down keys to select the required unit according to the type of transmitter.
Or when “00” blinks:
➢ Press Up or Down key to select the sub-folder “F 210” corresponding to the channel 2.
➢ Press Up and Down keys to select the required unit according to the type of transmitter.
“---” sign allows to deactivate the channel.
Units available according to the channel and the type of transmitter:
CP211-212-213-R: Pa, mmH
2
O, inWG, mbar, mmHg, daPa, kPa, hPa, m/s*, fpm*, m
3
/h*, l/s*, cfm*, m
3
/s*, dam
3
/h*, °C, °F
CTV210-R: m/s, fpm, km/h, m
3
/h, l/s, cfm, m
3
/s, dam
3
/h, °C, °F
COT212-R: ppm, °C, °F
TM210-R: °C, °F, dT,%RH, g/kg, kJ/kg, °C Td, °F Td, °C Tw, °F Tw, g/m³
TH210-R: %RH, g/kg, kJ/kg, °C Td, °F Td, °C Tw, °F Tw, °C, °F, g/m³
*: units regarding the air velocity and airflow calculation, available on CP211-212-213-R transmitters with SQR3 option only.
F 200: CHANNELS AND MEASUREMENT UNITS CONFIGURATION 11
