9.4. Setting of the type of section and airflow coefficient (CP210-R, CTV210-R)
This function is available for CP210-R transmitters with SQR3 option only.
9.4.1 Select the type of section
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 8).
➢ Press OK.
➢ Press Up key to go to “F 620” folder.
➢ Press OK.
➢ Select 0, 1, or 2 for:
➢ 0: rectangular section
➢ 1: circular section
➢ 2: coefficient*
9.4.2 Select the unit of the section
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 8).
➢ Press OK.
➢ Press Up key to go to “F 621” folder.
➢ Press OK.
➢ Select 0 or 1 for:
➢ 0: section in mm
➢ 1: section in inch
9.4.3 Set the size of the section
For a rectangular section:
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 8).
➢ Press OK.
➢ Press Up key to go to “F 622” folder to set the length of the rectangular section.
➢ Press OK.
➢ Set the length with Up and Down keys.
➢ Press OK when the last digit has been set to validate the length.
➢ Press Up key to go to “F 623” folder to set the width of the rectangular section
➢ Press OK.
➢ Set the width with Up and Down keys.
➢ Press OK when the last digit has been set to validate the width.
For a circular section:
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 8).
➢ Press OK.
➢ Press Up key to go to “F 624” folder to set the diameter of the circular section.
➢ Press OK.
➢ Set the diameter with Up and Down keys.
➢ Press OK when the last digit has been set to validate the diameter.
F 600: COMPENSATION, MEANS OF MEASUREMENT AND SECTION SETTINGS 23
*CP210-R only.
