Page #27 background imageLoading...
Page #27 background image
F 406 Safety relay 1 1: Positive safety / 0: Negative safety
F 410 Activation mode for relay 2 0: None
1: Rising edge
2: Falling edge
3: Monitoring
F 411 Channel selection relay 2 Channel 1
Channel 2
F 412 Threshold 1 relay 2 setting According to the connected probe
F 413 Threshold 2 or hysteresis relay 2 setting According to the connected probe
F 414 Delay 1 relay 2 setting From 0 to 600 seconds
F 415 Delay 2 relay 2 setting From 0 to 600 seconds
F 416 Safety relay 2 1: Positive safety
0: Negative safety
10.5. F 500
Code Transmitter Description Possibilities
F 500 CP210-R only Integration of the measurement (pressure) From 0 to 9
F 501 CTV210-R only Integration of the measurement (air
velocity)
From 0 to 9
F 510 CP210-R with
solenoid valve only
Time-delay between two auto-calibrations From 0 to 60 minutes
F 521 All Offset main parameter According to the measurement
range of the transmitter
F 531 All Offset secondary parameter According to the measurement
range of the transmitter
10.6. F 600
Code Transmitter Description Possibilities
F 600 CP210-R Temperature unit 0: °C
1: °F
F 602 CP210-R Temperature compensation
F 605 COT212-R, CP210-R and
CTV210-R
Altitude compensation
F 610 CP210-R Means of measurement 0: Pitot L
1: Pitot S
2: Debimo blade
3: Factor
F 611 CP210-R Differential pressure
coefficient
F 612 CP210-R and CTV210-R Factor of air velocity
correction
FUNCTIONS RECAP
27
