4. F 100: CONFIGURE THE TRANSMITTER
This folder allows to configure the following parameters of the transmitter: contrast, backlight and keypad locking.
It also indicates the firmware version of the transmitter.
4.1. Access to the firmware version
The activation code is validated and “F 100” is displayed (see previous page).
➢ Press OK.
“F 101” is displayed with the firmware version number above. (Ex: 1.04)
4.2. Configure the screen
4.2.1 Set the contrast: F 110
The transmitter is powered on.
➢ Press OK.
➢ Enter the activation code (see page 8).
➢ Press OK.
“F 100” folder is displayed.
➢ Press OK.
➢ Press Up key to go the “F 110” folder.
“F 110” is displayed with the number corresponding to the contrast level between 0 and 5.
➢ Press OK.
The contrast number blinks.
➢ Set it between 0 and 5 pressing Up and Down keys.
When pressing Up or Down key to change the contrast level, there is a lag time of 1 second where
the digits disappear then they reappear with the new contrast.
➢ Press OK.
4.2.2 Set the backlight duration: F 111
It is possible to set the backlight duration:
• 0: backlight is inactive
• 1: backlight lasts 10 s.
• 2: backlight lasts 30 s.
• 3: backlight lasts 60 s.
• 4: backlight is permanent.
Backlight is activated pressing any key (unless the level 0 is selected).
“
F 110” sub-folder is displayed.
➢ Press Up key.
“F 111” is displayed with the number corresponding to the backlight duration between 0 and 4.
➢ Press OK.
The backlight duration blinks.
➢ Set it between 0 and 4 pressing Up and Down keys.
➢ Press OK.
4.2.3 Set the backlight
“
F 111” sub-folder is displayed.
➢ Press Up key.
“F 112” is displayed with the number corresponding to the backlight level between 0 and 10.
F 100: CONFIGURE THE TRANSMITTER
9
