Kimo 210-R Series User Manual

➢ Press OK.
➢ Press Up key to go to the “F 392” folder corresponding to the duration between two purges.
➢ Press OK.
➢ With Up and Down keys, set the duration between two purges from 1 to 9999 minutes.
➢ Press OK.
➢ Press the Up key to go to the “F 393” folder corresponding to the delay setting.
➢ Press OK.
➢ With Up and Down keys, set the delay from 1 to 60 seconds.
➢ Press OK.
The purge duration must be between 1 and 60 seconds.
The duration between 2 purges must be between 1 and 9999 minutes.
The delay duration must be between 1 and 60 seconds.
Unit of measurement conversion chart
• Pressure
Pa mmH
2
O InWG mbar mmHG kPa PSI daPa hPa
CP211-R
±100 ±10.2 ±0.40 ±1.00 ±0.75 ±0.100 - ±10.0 ±1.00
CP212-R
±1000 ±102.0 ±4.01 ±10.00 ±7.50 ±1.000 - ±100.0 ±10.00
CP213-R
±10 000 ±1019.7 ±40.14 ±100.00 ±75.00 ±10.000 - ±1000.0 ±100.00
• Temperature
TH210-R °C °F
Ambient model From 0.0 to +50.0 From +32.0 to +122.0
Model with polycarbonate probe From -20.0 to +80.0 From -4.0 to +176.0
Model with stainless steel probe From -40.0 to +180.0 From -40.0 to +356.0
TM210-R °C °F
Ambient model From 0.0 to +50.0 From +32.0 to +122.0
Terminal block model From -100.0 to +400.0 From -148.0 to +752.0
CTV210-R / COT212-R °C °F
Ambient model From 0.0 to +50.0 From +32.0 to +122.0
CP210-R °C °F
On terminal block From -100.0 to +400.0 From -148.0 to +752.0
• Air velocity
CTV210-R m/s fpm km/h
Standard From 0 to 30 From 0 to 5905 From 0 to 108
F 300: ANALOGUE OUTPUTS MANAGEMENT 15
