Kimo C310 User Manual

➢ Go to “Probe 1” or “Probe 2” line (according to the channel of the air velocity/airflow probe) then press OK.
➢ Use Up/Down/Left/Right arrows to enter a correction factor then press OK.
The correction factor must be between 0.2 and 2.
Enter an integration in air velocity : The air velocity measurement element of the transmitter is very sensitive and reacts
to air velocity changes. When making measurements in unstable air systems, the air velocity measurement may fluctuate.
The integration coefficient (from 0 to 9) makes an average of the measurement ; this helps to avoid any excessive
variations and guarantees a stable measurement.
New displayed value = [((10 - Coef.) x New Value) + (Coef. x Old value)] /10
Example : C310 with hotwire (0-30 m/s) – Current measurement : 2 m/s – New measurement : 8 m/s
The air velocity source being unstable, the user selects a strong integration. Integration : 7. The variation is lower than 10
m/s, it is possible to apply the integration calculation formula.
Next displayed value : ((2 * 8) + (7 *2 ))/10 = 3 m/s.
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to the “Parameters” line then press OK.
➢ Go to “Probe 1” or “Probe 2” line (according to the channel of the air velocity/airflow probe) then press OK.
➢ Go to “Air velocity integration” line then press OK.
➢ Use Up and Down arrows to select an air velocity integration then press OK.
The air velocity integration must be between 0 and 9.
3.6.2 Configure a CO
2
probe or a temperature/hygrometry probe
A CO
2
probe or a temperature/hygrometry probe must be connected to the transmitter.
Set the compensation in atmospheric pressure
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to the “Parameters” line then press OK.
➢ Go to “Probe 1” or “Probe 2” (according to the channel of the CO
2
probe) then press OK.
➢ Go to “Compensation” line then press OK.
➢ Go to “Atmo pressure” line then select the unit with the Up and Down arrows.
➢ Press OK.
➢ Enter a value. This value must be between :
• 0 and 4000 hPa
• 0 and 4000 mbar
• 0 and 3000.24 mmHg
• 0 and 10 000 m (altitude)
3.6.3 Configure a board
A pressure board must be connected to the transmitter.
For the air velocity/airflow settings, the “Air velocity/airflow” option must be activated.
Select the measuring device :
➢ Press OK.
➢ Enter the security code then press OK.
➢ Go to the “Parameters” line then press OK.
19

Kimo C310 Specifications

General

Measured parameters	CO, Temperature
CO measurement range	0 to 500 ppm
CO resolution	1 ppm
Temperature accuracy	±0.5 °C
Temperature resolution	0.1 °C
Protection	IP65
Operating Humidity	0 to 95% RH (non-condensing)
Response Time	< 30 seconds
Power supply	24 V AC/DC
Output	4-20 mA
