Kimo C310 User Manual

4.3. Outputs
Modbus Register type Description Possibilities
3000 Enumeration Analogue output selection of the channel
1
4-20 mA / 0-20 mA / 0-10 V / 0-5 V
3100 Enumeration Analogue output selection of the channel
2
4-20 mA / 0-20 mA / 0-10 V / 0-5 V
3200 Enumeration Analogue output selection of the channel
3
4-20 mA / 0-20 mA / 0-10 V / 0-5 V
3010 Real Channel 1 minimum range From -1999 to 9999
3020 Real Channel 1 maximum range From -1999 to 9999
3110 Real Channel 2 minimum range From -1999 to 9999
3120 Real Channel 2 maximum range From -1999 to 9999
3210 Real Channel 3 minimum range From -1999 to 9999
3220 Real Channel 3 maximum range From -1999 to 9999
3030 Enumeration Channel 1 diagnostic : generation of a
current or a voltage
Generation according the output signal
0-10 V 0-5 V 0-20
mA
4-20
mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10
mA
12
mA
10 V 5 V 20
mA
20
mA
3130 Enumeration Channel 2 diagnostic : generation of a
current or a voltage
Generation according the output signal
0-10 V 0-5 V 0-20
mA
4-20
mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10
mA
12
mA
10 V 5 V 20
mA
20
mA
3230 Enumeration Channel 3 diagnostic : generation of a
current or a voltage
Generation according the output signal
0-10 V 0-5 V 0-20
mA
4-20
mA
0 V 0 V 0 mA 4 mA
5 V 2.5 V 10
mA
12
mA
10 V 5 V 20
mA
20
mA
25

Kimo C310 Specifications

General

Measured parameters	CO, Temperature
CO measurement range	0 to 500 ppm
CO resolution	1 ppm
Temperature accuracy	±0.5 °C
Temperature resolution	0.1 °C
Protection	IP65
Operating Humidity	0 to 95% RH (non-condensing)
Response Time	< 30 seconds
Power supply	24 V AC/DC
Output	4-20 mA
