Kimo C310 User Manual

1.3. Protection tips of the sensor
It's extremely unwise to remove the protection tip of our hygrometry probes as
the sensitive element is very fragile even to light contacts. However, if you
have to remove the protection tip, take all possible precautions and avoid any
contact with the sensitive element.
To remove the protection tip, unscrew it or unclip it.
6
Protection tip
to unscrew
Protection tip
to unscrew
Sensitive
element
Sensitive
element

Kimo C310 Specifications

General

Measured parameters	CO, Temperature
CO measurement range	0 to 500 ppm
CO resolution	1 ppm
Temperature accuracy	±0.5 °C
Temperature resolution	0.1 °C
Protection	IP65
Operating Humidity	0 to 95% RH (non-condensing)
Response Time	< 30 seconds
Power supply	24 V AC/DC
Output	4-20 mA
