Kimo C310 User Manual

3.2.1 Set the screen
➢ Press OK on “Screen” line.
➢ Press OK on “Contrast” line to set the contrast between 0 and 3.
➢ Use Up and Down keys to set the contrast then press OK.
➢ Go to the “Backlight settings” line with the Down key then press OK.
➢ Press OK on “Duration” line then select the backlight duration with Up and Down keys :
• ON : continuous backlight
• 10 sec, 30 sec or 1 min : backlight turns off as soon as the selected time is up.
• OFF : deactivated backlight
➢ Press OK to validate.
➢ Press Down key then OK on “Backlight” line.
➢ Set the backlight between 0 and 10 with Up and Down keys.
➢ Press OK to validate.
➢ Press Esc to back to the configuration screen of the device.
3.2.2 Set the graphical period
➢ Press OK “Graphical period” line.
➢ Use Up and Down keys to select the requested duration then press OK to validate.
Example : if 15 min is selected, the transmitter will graphically display the measured values during the last 15
minutes.
3.2.3 Set the language
➢ Press OK on “Language” line.
➢ Select the language with Up and Down keys : Frencjh or English.
➢ Press OK to validate.
3.2.4 Set date and time
➢ Press OK on “Date-Time” line.
“Date-time” screen is displayed.
➢ Press OK on “Date” line then select with Up and Down keys the date format :
• JJ/MM/AAAA : day/month/year
• MM/JJ/AAAA : month/day/year
• AAAA/MM/JJ : year/month/ day
➢ Press OK.
➢ Go the number to modify with Up/Down/left/right keys then press OK.
➢ Enter the required number with Up/Down/left/right keys then press OK.
➢ Once the settings are performed, press Esc key to validate the date and time and to back to the configuration
screen of the device.
3.2.5 Activate /deactivate the beep key
➢ Press OK on “Beep key” line.
➢ Select “YES” to activate the beep key or “NO” to deactivate it.
➢ Press OK to validate.
3.2.6 Lock and unlock the keyboard
➢ Press OK on “Keyboard Lock” line.
➢ Select “YES” to lock the keyboard then press OK.
A message is displayed indicating that the keyboard is locked and the device backs to measurement screen.
Press OK during 6 s to unlock the keyboard.
11

Kimo C310 Specifications

General

Measured parameters	CO, Temperature
CO measurement range	0 to 500 ppm
CO resolution	1 ppm
Temperature accuracy	±0.5 °C
Temperature resolution	0.1 °C
Protection	IP65
Operating Humidity	0 to 95% RH (non-condensing)
Response Time	< 30 seconds
Power supply	24 V AC/DC
Output	4-20 mA
