Kinematica MEGATRON MT 3100 S2 - Description of the Equipment

INSTRUCTION MANUAL
System
MEGATRON
®
Type
MT 3100 S
2
Issue
3.1 / 29.01.2019
Page
14
of
39
2 DESCRIPTION OF THE EQUIPMENT
For a ready-to-use system you will need:
• Drive unit MEGATRON
®
MT 3100 S²
• A working chamber MTO/MTK 3100 Q
• A recirculation system (can also be supplied by the customer)
Example of a customized and extended
Drive
Unit
Working
Chamber
