• Check that the quick coupling has secured the working chamber against turn-
ing and/or removing.
• To remove the working chamber from the drive unit, simply push back the
slide ring of the quick coupling and carefully remove the working chamber
from the coupling.
• Connect product inlet and outlet lines and necessary supply lines (e.g. cooling
water, sealing liquid…). A seal should always be used to avoid leakages. The
piping should not generate any forces (stresses, vibrations) on the working
chamber nozzles.
3.1.2
ELECTRICAL INSTALLATION
Before connecting the electrical power supply using the mains cable, check the
“Technical Data” as well as the data on the drive tag plate.
3.2 START-UP
• Check if all connections, piping and supply lines are tight and mounted cor-
rectly.
• Remove the cover of the quench vessel and fill up the quench system with
the sealing liquid.
• The sealing liquid has to be compatible with the product, the seals and the
mechanical seal. The sealing liquid is not within the scope of supply of
KINEMATICA.
• Use enough sealing liquid so that the standpipe is always covered. Otherwise
the mechanical seal will be damaged.
• Check that the filling level remains constant.
• Open the inlet and outlet product circuits.
• Check all connections, piping and supply lines for signs of leakage.
