7 TECHNICAL DATA
7.1 DRIVE UNITS
Description
Drive Unit MEGATRON
®
MT 3100 S²
Order Code
13010060
13010061
13010062
13010063
Plug type
CH
EU
UK
US
Motor type
AC motor 3-phase, gear-free direct drive
Supply voltage
1-phase, 230 V ~
Supply frequency
50-60 Hz
Max. speed 30’000 rpm (+/- 2%)
Input power
Max. 1’500 W
Output power
Max. 1’200 W
Soft-start
Yes
Noise emission (drive
only)
Lower than 62 dB(A)
Direction of rotation
Counter clockwise, seen from front
Ambient temperature
0 – 40°C
Relative humidity
80% max.
non-condensing
Standards
Manufactured according to EN / IEC regulations for
EMC & SAFETY
Protection type
IP 20
Max. period of continuous
operation
100 %
Coupling type
F
Weight (drive only)
10.2 kg
220 mm
275 mm
245 mm
