2.2 WORKING CHAMBER
The working chamber is a flow through in line chamber.
The working chamber consists of the following general parts:
• Bearing
• Mechanical sealing
• Inner chamber with dispersing generator and product inlet/outlet connections
• Cooling/heating jacket (if applicable)
Product
Inlet
Product
Outlet
Dispersing
Generator
Coupling /
Bearing
Mechanical
Seal
Quench
System TS1
