16. Technical specications
King Gates srl, in order to improve its products, reserves the right to modify their technical specications at any time without prior notice. In
any case, the manufacturer guarantees their functionality and suitability for the intended purposes.
All the technical characteristics refer to a room temperature of 20°C (±5°C).
OVO technical specifications
Type Electromechanical gearmotor for the automatic movement of garage doors for residential use,
complete with electronic control unit
Pinion 9.5 mm diameter, 28 teeth
Peak starting torque [corresponds to
the force necessary to keep set the
leaf in motion]
620N
Speed under no load [corresponds if
"Fast" speed is programmed]
0.17m/s
Maximum frequency of operating cycles 30 cycles per day (the control unit allows up to the maximum described in tables 2 and 3)
Maximum continuous operating time
3 minutes (the control unit limits the continuous operation up to the maximum described in tables 2 and 3)
Operating limits In general, ELEVO is suitable for the automation of sectional or overhead doors which remain
within the dimensions stated in table 1 and limits specified in tables 2 and 3.
ELEVO power supply 230Vac (±10%) 50/60Hz.
Max. absorbed power 200 W
Insulation class 1 (a safety grounding system is required)
Emergency power supply No
ELEVO courtesy light LED
Flashing Light Output for 1 flashing light (24V, 15W)
Working temp. -20°C ÷ +55°C
Use in acid, saline or potentially
explosive atmosphere
No
Protection class IP 40 use only in indoor or protected environments
Dimensions and weight 225 x 330 h 100 / 3.3 kg
Guide technical characteristics
GRO33 GRO13
Type 3-piece profile in galvanised steel single profile in galvanised steel
Guide length 3.15 m 3.15 m
Guide height 35 mm 35 mm
Useful stroke 2.6 m 2.6 m
Belt lenght 6 m 6 m
Belt height 6 mm 6 mm
Resistance to traction 730 N 730 N
Incorporated radio receiver technical specifications
Type 4 channel receiver for incorporated radio command
Frequency 433.92 MHz
Coding King
Transmitter compatibility (*) DigyPad, Stilo 4K, Myo C4, Novo TX and Novo Digy
No. of transmitters that can be
memorised
170 remotes
Input impedance 50 Ω
Sensitivity better than 0.5µV
Range of the transmitters From 100 to 150m. The range can vary if there are obstacles or electromagnetic disturbances,
and is also affected by the position of the receiving aerial
Outputs /
Working temp. -20°C ÷ 55°C
