17
Pedal Assist Parameter Setting
Pedal Assist Level Option
SAC means pedal assist parameter setting. In Pedal assist level
setting , there are 8 modes to select: 0-3, 1-3, 0-5, 1-5, 0-7, 1-7, 0-9,
1-9. Press UP/DOWN to select, press MODE to confirm and enter
into the Pedal assist ratio setting.
Pedal assistant level option interface
Pedal Assist Ratio Modification
To modify the value of Pedal assistant ratio will meet the different
requirements.
Take the level 1 for example, “30-50 percent” is the recommended
range, “40” is the present value (i.e. 40% output). Press UP/DOWN
to select, shortly press MODE to confirm and enter into the next
Pedal assistant ratio setting. After all inputted, hold MODE over 2
seconds to confirm the modification and turn back to personalized
parameter setting interface. For the details, please see Appendix 4.
