Kinze 3600 - SINGLE AND TWO-SPEED POINT ROW CLUTCH MAINTENANCE

M0259-01Model 3600
6-26 9/14
TM
Lubrication and Maintenance
SINGLE AND TWO-SPEED POINT ROW CLUTCH MAINTENANCE
Point row clutch is permanently lubricated and sealed and requires no periodic maintenance. Two-speed point row clutch
is similar in design and operation to standard point row clutch except for two-speed function.
Solenoid
Single point row clutch main parts
Two-speed point row clutch main parts
Input hub
Output hub
Wrap spring
Stop collar
Actuator arm
Plunger
Spring
Stop collar
Actuator arm
Plunger
Input hub
Output hub
Wrap spring
Solenoid
Spring
Wrap spring
Stop collar
