PERIODIC SERVICE 12-9
196OC16A196OC15A
(1) Grease Fitting (Top Link) (1) Battery (2) Battery Terminals
196OC17A
(1) Bolt : 83 N·m (8.5 kgf·m, 62 lbf·ft)
Nut : 68 N·m (7 kgf·m, 50 lbf·ft)
(2) Bolt, Nut : 215 N·m (22 kgf·m, 160 lbf·ft)
Check wheel bolts and nuts regularly
especially when new. If they are loose,
tighten them as follows.
CHECKING WHEEL BOLT
TORQUE
CAUTION
To avoid personal injury:
Never operate tractor with a
loose rim, wheel, or axle.
Any time bolts and nuts are
loosened, retighten to specified
torque.
Check all bolts and nuts fre-
quently and keep them tight.
To Next Page
