OPERATING THE TRACTOR 7-3
196O702A196O701A
OPERATING ROPS
TO FOLD THE ROPS
(1) Bolt
(2) Nut
(1) ROPS
1. Remove the nut and bolt. 2. Fold the ROPS.
CAUTION
To avoid personal injury:
Hold the ROPS tightly with both
hands and fold the ROPS slowly
and carefully.
196O703A
(1) Bolt
(2) Nut
3. Align bolt holes, insert both bolt, and
secure them with the nut.
CAUTION
You should always stop the
engine, remove the key and set
the parking brake before raising
or folding the rops.
Always perform such tasks from
a safe and stable position at the
rear of the tractor.
Folding the ROPS should only be
done when absolutely necessary,
and should be returned to the up-
right position as soon as possible.
CAUTION
To avoid personal injury:
Make sure the bolt are properly
installed and secured.
