OPERATING THE ENGINE 6-3
196O603A196O602A
PLACE THE P.T.O CLUTCH LE-
VER IN “OFF” POSITION.
PLACE THE SPEED CON
TROL PEDAL IN “NEUTRAL”
POSITION.
PLACE THE RANGE GEAR
SHIFT LEVER (HI-LO) IN
“NEUTRAL” POSITION.
(1) P.T.O Clutch Lever
(2) Speed Control Pedal
(3) Range Gear Shift Lever (Hi-Lo)
“ON”
“OFF”
“HI”
(N) “NEUTRAL POSITION”
“Lo”
(1) Hydraulic Control Lever
(A) “DOWN”
MOVE THE HYDRAULIC
CONTROL LEVER FORWARD.
To lower implement, move the hydraulic
control lever forward.
Hydraulic control lever is automatically
returned to neutral position when imple-
ment is down at lowest position.
NOTE
The speed control pedal automatically
return to neutral when the operator’s
foot is released from the pedal.
