KIP 7100 - Finalizing Fuser Jam Clearance; Closing Fuser Door and Exit Cover; Securing Engine Unit and Trays

Chapter 3 Error Correction 3-9
7. Close Fuser Door (5) and Exit Cover (3).
8. Gently close the Engine Unit.
9. Replace Print Trays in the original position.
NOTE
Be sure to close the Engine Unit firmly until it locks at the correct position.
5 3
