KIP 7100 - Scanner Unit Internal Cleaning; Wiping Feed and Press Rollers; Scanner Unit Closing Procedure

Chapter 4 Maintenance 4-3
4. Wipe the Feed Rollers (4), Press Rollers (5) and the inside surface with a soft dry cloth.
5. Gently press Scanner Unit down and firmly close it.
NOTE
Press down Scanner Unit on both side to close it.
Do not close it by pressing only one side down.
4
4
5
