DP405 Service Manual
Appendix 2 Material List（electronic section）
List 1 DP405－02 Motherboard material list
No. Part No. Part Name Description Quantity Position
1 4SM7-6027-A40B mic
Φ6.0mm, height
2.7mm,-40dB±2dB,all
direction,2.2KΩ,
1 MIC600
2 3CE3-CZ25-D
2.5mm earphone
jack
PJ-208B, height
4.5mm,pin length 2.5mm;
lead-free
1 J601
3 3CE3-CZ35-F
3.5mm earphone
jack
PJ-3511-0 lead-free, with
switch
1 J600
4
2RW3-RP08110S
NJX-V01
Volume switch RP08110SNJX-V01-0001 1 POW&VOL
5
3SE3-RE08220HX
-V02
Channel switch 4.75mm shaft, 1 S200
6 6PM7-4169-HMB
DP405 UHF
motherboard
DP405-02_MAINBOARD_
160512,
1
7 2RS1-10-000O R flake resistor 1005,0Ω 30
C28,R45,C32,R109,R14,R167,R11,R251,R252,C569,
C570,C577,R17,R504,R516,R555,R32,C19,R624,R4
1,R26,R48,R43,R71,R72,R15,C44,C45,C73,C74
27
