DP405 Service Manual
2 7MHP-4141-04C-W0 S8 volume knob ABS,black cool gray 1
3 7MHP-7210-03C-W0 PT567 channel knob ABS,black pantone cool gray 6C 1
4 7MHP-4097-02A-W0
Earphone jack waterproof
pad
TPU: black textured, lead-free 1
5 7MHL-4141-01A-N S8 aluminum shell lead-free 1
6 7MHR-4038-02A-W0 S760main wanterproof ring Silica gel, black, high-gloss, lead-free 1
7 7MHR-4038-04A-W0 S760top waterproof pad Silica gel, black, polished, lead-free 1
8 7MHR-4038-05A-W0 S760 pin jack Silica gel, black, polished, lead-free 1
9 7MHS-4038-02B-W S760 PTT key metal dome lead-free 1
10 7NRC-060090035-W1 S760(DP460) channel nut
brass, internal diameter M6mm, external
diameterφ9mm, 3.5mm thick, lead-free
2
11
7SMF-020040M-SZYB-
N
R M2*4 cross machine
screw
(558/PT4200/PT558S/5200/P
T(priority)
Φ2mm*4mm 8
12
7SMF-020080M-MHHT-
N1
R M2*8 torx machine
screw558/E66/PT558/4200/P
T4200/5200(priority)
Φ2mm*8mm 2
13 7MHR-7042-06B-W0 R conducted silica gel pad Silica gel, black, 3*6*9mm, lead-free 1
14 3CR7-SMA-50JF-4 R RF coaxial connetcor SMA-J, flange plate installation 1
