Kirisun DP480 Service Manual

DP480 Service Manual
27
SN
Material Code
Material Name
Specification
QTY
18
7MHS-4245-02A-W
LCD hardware holder
SUS304, 48hr salt spray test
passed
1
19
7STF-019047B-
SZHT-X
M1.9*4.7 thick-head
self-tapping Phillips
screw
Material: harden iron,
Φ1.9mm*4.7mm, flat-head, with
guide, radiant plated
2
20
7SMF-020040M-
SZYB-N
M2*4 cross recessed
mushroom-head
machine screw
Harden iron, Φ2mm*4mm cross
recessed mushroom-head nickel
plated machine screw, nylok
8
21
7MHR-4072-05A-W0
O-shaped ring of
power key
Silicon rubber, outer diameter
8mm, wire diameter 1.5mm
2
22
7SMF-020037M-
SZCT-N
Cross recessed
countersunk-head
machine screw
Harden iron 1018,
Φ2.0mm*3.7mm, nickel plated
2
23
7MHS-4207-03A-W
DP586 PTT metal
dome array
SUS301, Φ5mm, four-point metal
dome
1
24
6PD7-4207-HPC
DP586 PTT plate
0.8mm thick, FR-4, 52X10mm
1
25
3CR7-SMA-50JF-4
RF coaxial cable
SMA-J, flange
1
26
7MHR-4207-06A-W0
DP586 O-shaped ring
of antenna pedestal
Material: silicon rubber, outer
diameter 11mm, wire diameter
1.5mm
1
27
7MHP-4253-04A-W0
DP485 waterproof
pad for earphone jack
TPU, black, etched
1
28
7MHP-4207-03A-W0
DP586 top cover
PC1414, black
1
29
6SS3-DC7258-A
KB-75A battery
7.4V,2000mAh, Li-ion battery
1
30
63BJ000002
KBJ-17 belt clip (S
series)
S760/DP405 belt clip
1
31
7SMF-025080M-
SZYB-Z
M2.5*8 cross round-
and-mushroom
headed machine
screw
Stainless steel, Φ2.5mm*8mm,
black zinc plated, lead free
2
32
7MHR-4207-01A-W3
DP586 waterproof
ring
Silicon rubber, pantone 172C,
hardness 40±5°
1
33
7MHR-4182-01A-W0
DP990 discharge
waterproof pad
Hardness 30, silicon rubber,
orange PT172C
1
34
157F15000083
waterproof pad for
aluminum shell
Material: white waterproof sound-
transmitting membrane with
1
