Kirisun DP480 Service Manual

DP480 Service Manual
34
Appendix 2 Material List (Electronic Part)
Table 1 Material List of Main Board 400~470MHz
SN
Material Code
Material Name
Specification
QTY
Position
1
133C07000002
3.5mm earphone socket
Material NO.: PJ-3511-0; 4-pin, with
switch, lead free
1
J600
2
3SE3-ED08E42S-
FE15C7
Power encoder switch
ED08E42S-FE15C7.0-A16-1020, with
location column, 4.75mm axis, 15mm
long
1
S3
3
3SE3-ED08C03O-
FE18C9
PT118D #encoder switch
ED08C03O-FE18C9.0-A16-1002, axis
4.75mm thick, M6 thread
1
S200
4
3CE3-ST-2004
2.5mm earphone socket
SI-2004, 4mm high, lead free
1
5
7MHP-4253-05A-JC
DP485 Potentiometer
gasket
DP485, Potentiometer gasket, PVC,
transparent
1
6
2CC1-20-X5R160-
106KD
Multi-layer chip capacitor
EMK212ABJ106KD-T,2012,10uF±
10%,16V,TAIYO,0.85±0.1mm high
16
C28,C47,C103,C108,C119,C123,C20,
C39,C91,C106,C582,C86,C615,C312
,C315,C606
7
2CC1-10-X7R500-
471K
Multi-layer chip capacitor
murata,GRM155R71H471KA01D,470,p
F,±10%,50V,1005,X7R
51
C55,C102,C104,C113,C118,C122,C1
4,C7,C8,C9,C10,C11,C64,C65,C66,C
67,C230,C231,C232,C233,C237,C23
8,C239,C240,C241,C242,C243,C332,
C107,C519,C522,C523,C528,C530,C
531,C532,C533,C535,C537,C538,C5
