Kirisun DP480 Service Manual

DP480 Service Manual
35
41,C549,C550,C551,C553,C554,C55
9,C564,C565,C21,C333
8
2CC1-10-X7R500-
103K
2CC1-10-X7R500-471K
MURATA,GRM155R71H103KA88D,10,
nF,±10%,50V,0402,X7R
18
C61,C110,C112,C115,C12,C17,C57,
C58,C326,C327,C328,C329,C529,C5
39,C540,C42,C49,C612
9
2CC1-10-X7R160-
104K
2CC1-10-X7R500-471K
MURATA,GRM155R71C104KA88D,100
,nF,±10%,16V,0402,X7R
17
C609,C604,C101,C111,C114,C117,C
5,C13,C18,C346,C56,C15,C22,C33,C
43,C46,C616
10
2RS1-10-155J
Chip resistor
yageo,RC0402JR-071M5L,1.5,MΩ,±
5%,0402
1
C109
11
2CC1-10-X7R500-
102K
Multi-layer chip capacitor
MURATA,GRM155R71H102KA01D,1,n
F,±10%,50V,0402,X7R
14
C120,C124,C526,C536,C573,C581,C
31,C93,C94,C95,C96,C98,C613,C61
4
12
1DR1-1SR154-400
SMD rectifier diode
rohm,1SR154-
400,4.5mm*2.6mm*2.0mm,-55℃ to
150℃
1
D100
13
121D03000007
SMD Schottky barrier
diode
SD103AW,SOD-323，
2.7mm*1.35mm*1.0mm,-55℃ to
150℃,
1
D101
14
3FW1-42932-302320
SMD fuse
littelfuse,429003/433003/466003,3216,
3A/32V
1
F100
15
1IS1-
XC6204B502MR
SMD voltage regulator IC
XC6204B502MR,SOT-25,-40~85°
1
IC100
16
1IS1-MP2359
SMD switch power supply
IC
MPS,MP2359,TSOT23-6,-40 to +85℃
1
IC102
17
135F04000011
Magnetic beads
GZ1608U601CTF,1608,
12
L30,L100,L104,L105,L1,L2,L300,L51
5,L521,L31,L600,L38
