Kirisun DP480 Service Manual

DP480 Service Manual
36
18
2LG1-VLS3012ET-
100M
SMD power inductor
TDK,VLS3012ET-100M,10,uH,±
20%,3*3*1.2
1
L107
19
1TT1-KTA1298-Y
R SMD transistor
KEC,KTA1298-Y,SOT-23,-~150℃
1
Q102
20
1TT1-DTC144EE
R SMD transistor
ROHM,DTC144EE,EMT3,-~150℃
9
Q103,Q1,Q3,Q200,Q201,Q4,Q7,Q10,
Q606
21
2RS1-10-222J
R Chip resistor
yageo,RC0402JR-072K2L,2.2,KΩ,±
5%,0402
3
R102,R246,R247
22
2RS1-10-103J
R Chip resistor
yageo,RC0402JR-0710KL,10,KΩ,±
5%,0402
19
R103,R110,R1,R48,R52,R53,R55,R5
7,R58,R59,R68,R70,R245,R601,R61
4,R172,R173,C611,R86
23
2RE1-10-1602
SMD precision resistor
YAGEO,RC0402FR-0716K2L,16.2,KΩ,
±1%,0402
1
R106
24
2RS1-10-104J
R Chip resistor
yageo,RC0402JR-07100KL,100,KΩ,±
5%,0402
1
R63
25
2RS1-10-102J
R Chip resistor
yageo,RC0402JR-071KL,1KΩ,±
5%,0402
19
R108,R3,R50,R60,R236,R237,R238,
R239,R6,R10,R502,R539,R544,R545
,R547,R551,R560,R623,R340
26
2CC1-10-X7R160-
333K
2CC1-10-X7R500-471K
MURATA,GRM155R71C333KA01D,33,
nF,±10%,16V,0402,X7R
4
C99,C100,C125,C583
27
2CC1-10-X5R100-
474K
2CC1-10-X7R500-471K
MURATA,GRM155R61A474KE15D,470
,nF,±10%,10V,0402,X5R
15
C105,C126,C127,R61,R62,C313,C31
4,C316,C317,C318,C319,C320,C321,
C322,C323
28
61SL000016
Module HS8861
Module HS8861
1
IC1
29
2RS1-16-000O
R Chip resistor
yageo,RC0603JR-070RL,0,Ω,±
5%,1608
10
R96,R97,L8,L6,L33,L510,R9,R519,R
49,R90

Kirisun DP480 Specifications

General

Brand	Kirisun
Model	DP480
Category	Two-Way Radio
Language	English
