Kirisun DP480 Service Manual

DP480 Service Manual
37
30
2RS1-10-471J
R Chip resistor
yageo,RC0402JR-07470RL,470,Ω,±
5%,0402
4
R14,R612,R615,R622
31
2RS1-10-000O
R Chip resistor
yageo,RC0402JR-070RL,0,Ω,±
5%,0402
36
C75,R43,R45,R46,R47,R71,R72,R16
7,R11,R26,R92,R251,R252,C73,C569
,C570,C577,R504,R516,R555,C48,C
53,R7,R20,R32,R82,R83,R88,R624,C
80,R76,R101,R112,R171,R21,IC301
(pin 2 and pin 3)
32
2RS1-10-332J
R Chip resistor
yageo,RC0402JR-073K3L,3.3,KΩ,±
5%,0402
2
R56,R81
33
1IS1-MCP4802-A
D/A converter IC
MICROCHIP,MCP4802
1
U20
34
2CC1-10-C0G500-
101J
2CC1-10-X7R500-471K
MURATA,GRM1555C1H101JA01D,100
,pF,±5%,50V,0402,C0G
5
C1,C2,C24,C324,C325
35
2CC1-10-Y5V160-
105Z
2CC1-10-X7R500-471K
murata,GRM155R61C105KA12D,1,uF,
+80%/-20%,16V,1005,Y5V
10
C38,C134,C136,C137,C138,C139,C1
40,C141,C142,C59
36
2RS1-20-000O
R Chip resistor
yageo,RC0805JR-070RL,0,Ω,±
5%,2012
1
C337
37
124P01000006
SMD light emitting diode
,HJ-19URC-
T6,red,2V@20mA,1.6mm*0.8mm*0.6m
m,-40~85°C,
1
D203
38
124P01000007
SMD light emitting diode
HJ-19YGC-T6,
chartreuse,2V@20mA,1.6mm*0.8mm*0
.6mm,-40~85°C,
1
D205
39
121I04000031
SMD linear IC
LM2904XTS8G/TR,TSSOP-8,-40℃
to125℃,
2
IC500,IC302
