Kirisun DP480 Service Manual

DP480 Service Manual
38
40
3CF1-BL112-30RU
SMD FFC/FPC connector
0.5-3-30P,lower flip connector,H=2.0
1
J201
41
5FE1-CB100505-102
SMD EMI filter
CB100505-102,1005.0
25
L7,L9,L10,L11,L12,L13,L14,L15,L16,L
17,L18,L19,L20,L21,L22,L23,L24,L25
,L26,L27,L28,FB1,FB17,FB20,FB41
42
1TF1-ST2301
R SMD field effect
transistor
Stanson,ST2301,SOT-23-3L,-~150℃
2
Q20,Q600
43
2RS1-16-220J
R Chip resistor
yageo,RC0603JR-0722RL,22,Ω,±
5%,1608
2
R2,R5
44
2RE1-10-6802
SMD precision resistor
yageo,RC0402FR-0768KL,68,KΩ,±
1%,0402
1
R104
45
2RS1-10-302J
R Chip resistor
yageo,RC0402JR-073KL,3,KΩ,±
5%,0402
1
R22
46
2RS1-10-153J
R Chip resistor
yageo,RC0402JR-0715KL,15,KΩ,±
5%,0402
2
R512,R542
47
2RS1-10-333J
R Chip resistor
yageo,RC0402JR-0733KL,33,KΩ,±
5%,0402
6
R65,R67,R18,R31,R616,R617
48
2RS1-10-100J
R Chip resistor
yageo,RC0402JR-0710RL,10,Ω,±
5%,0402
3
R66,R244,R559
49
2RS1-10-473J
R Chip resistor
yageo,RC0402JR-0747KL,47,KΩ,±
5%,0402
20
R77,R78,R79,R80,R240,R241,R242,
R243,R265,R266,R267,R268,R501,R
508,R513,R540,R541,R557,R558,R5
26
50
2RS1-10-221J
R Chip resistor
yageo,RC0402JR-07220RL,220,Ω,±
5%,0402
2
R249,R250
