Kirisun DP480 Service Manual

DP480 Service Manual
39
51
3ST1-SKRTLBE010
SMD tact switch
ALPS,SKRTLBE010,4.5*3.55*3.3mm,-
40 to +90℃
1
S1
52
1ID1-MXD2020ML
Accelerometer
memsic,MXD2020ML,LCC-8 ，
5.0mm*5.0mm*1.99mm,-40℃ to 105℃
1
U4
53
2CC1-10-X7R500-
271K
R Multi-layer chip
capacitor
MURATA,GRM155R71H271KA01D,270
,pF,±10%,50V,0402,X7R
1
C36
54
2CC1-10-X7R160-
473K
R Multi-layer chip
capacitor
MURATA,GRM155R71C473KA01D,47,
nF,±10%,16V,0402,X7R
2
C40,C16
55
2CC1-16-C0G500-
330J
Multi-layer chip capacitor
murata,GRM1885C1H330JA01D,33,pF,
±5%,50V,1608,C0G
1
C501
56
2CC1-16-C0G500-
3R0B
Multi-layer chip capacitor
murata,GRM1885C1H3R0BA01D,3,pF,
±0.1pF,50V,1608,C0G
1
C503
57
2CC1-16-C0G500-
2R0B
Multi-layer chip capacitor
murata,GRM1885C1H2R0BA01D,2,pF,
±0.1pF,50V,1608,C0G
2
C504,C505
58
2CC1-16-C0G500-
120J
R Multi-layer chip
capacitor
murata,GRM1885C1H120JA01D,12,pF,
±5%,50V,1608,C0G
1
C507
59
2CC1-16-C0G500-
8R0D
R Multi-layer chip
capacitor
murata,GRM1885C1H8R0DA01D,8,pF,
±0.5pF,50V,1608,C0G
2
C509,C502
60
112C03000273
Ceramic capacitor
YAGEO,CC0603JRNPO9BN680,68pF,
±5%,50V,0603,NPO
1
C510
61
2CC1-16-C0G500-
121J
R Multi-layer chip
capacitor
murata,GRM1885C1H121JA01D,120,p
F,±5%,50V,1608,C0G
1
C511
62
2CC1-10-C0G500-
330J
R Multi-layer chip
capacitor
MURATA,GRM1555C1H330JA01D,33,
pF,±5%,50V,0402,C0G
2
C512,C521
