Kirisun DP480 Service Manual

DP480 Service Manual
40
63
2CC1-16-C0G500-
2R0C
R Multi-layer chip
capacitor
murata,GRM1885C1H2R0CA01D,2,pF,
±0.25pF,50V,1608,C0G
1
C514
64
2CC1-16-C0G500-
5R0B
Multi-layer chip capacitor
murata,GRM1885C1H5R0BA01D,5,pF,
±0.1pF,50V,1608,C0G
2
C515,C516
65
2CC1-16-C0G500-
7R0C
Multi-layer chip capacitor
murata,GRM1885C1H7R0CA01D,7,pF,
±0.25pF,50V,1608,C0G
1
C517
66
2CC1-10-C0G500-
200J
R Multi-layer chip
capacitor
MURATA,GRM1555C1H200JA01D,20,
pF,±5%,50V,0402,C0G
1
C518
67
2CC1-10-C0G500-
6R0C
R Multi-layer chip
capacitor
MURATA,GRM1555C1H6R0CA01D,6,p
F,±0.25pF,50V,0402,C0G
2
C520,C561
68
2CC1-10-X7R500-
472K
Multi-layer chip capacitor
MURATA,GRM155R71H472KA01D,4.7,
nF,±10%,50V,0402,X7R
1
C527
69
2CC1-16-C0G500-
2R5B
R Multi-layer chip
capacitor
murata,GRM1885C1H2R4BA01D,2.4,p
F,±0.1pF,50V,1608,C0G
2
C534,C513
70
2CC1-10-X7R500-
153K
R Multi-layer chip
capacitor
MURATA,GRM155R71H153KA12D,15,
nF,±10%,50V,0402,X7R
2
C547,C545
71
2CC1-10-C0G500-
470J
R Multi-layer chip
capacitor
MURATA,GRM1555C1H470JA01D,47,
pF,±5%,50V,0402,C0G
3
C558,C560,C54
72
2RS1-10-561J
R Chip resistor
yageo,RC0402JR-07560RL,560,Ω,±
5%,0402
1
C578
73
2CC1-10-X7R250-
223K
R Multi-layer chip
capacitor
MURATA,GRM155R71E223KA61D,22,
nF,±10%,25V,0402,X7R
1
C584
74
1DS1-RN142S
SMD switch diode
ROHM,RN142S,1.6mm*0.8mm*0.6mm,
-55℃ to 150℃
2
D500,D501

Kirisun DP480 Specifications

General

Brand	Kirisun
Model	DP480
Category	Two-Way Radio
Language	English
