Kirisun DP480 Service Manual

DP480 Service Manual
59
136
2RS1-10-4R7J
R Chip resistor
yageo,RC0402JR-074R7L,4.7,Ω,
±5%,0402
2
R84,R85
137
2RS1-10-562J
R Chip resistor
yageo,RC0402JR-075K6L,5.6,KΩ,
±5%,0402
1
R613
138
2RS1-10-182J
R Chip resistor
yageo,RC0402JR-071K8L,1.8,KΩ,
±5%,0402
1
R618
139
2RS1-10-393J
R Chip resistor
yageo,RC0402JR-0739KL,39,KΩ,
±5%,0402
1
R631
140
1IS1-TDA2822
SMD IC
UTC,TDA2822,SOP8,-20 to +85℃
1
U600
141
2CC1-10-C0G500-
6R8C
Multi-layer chip capacitor
MURATA,GRM1555C1H6R8CA01
D,6.8,pF,±0.25pF,50V,0402,C0G
1
C32
142
2CC1-10-C0G500-
2R5B
R Multi-layer chip capacitor
SU,MURATA,GRM1555C1H2R5BA
01D,2.5pF,±0.1pF,50V,0402,C0G
4
C60,C69,C70,C71
143
2CC1-10-C0G500-
2R0B
Multi-layer chip capacitor
MURATA,GRM1555C1H2R0BA01
D,2,pF,±0.1pF,50V,0402,C0G
1
C72
144
5FE1-CB100505-102
SMD EMI filter
CB100505-102,1005.0
25
FB1,FB17,FB20,FB41,L7,L9,L10,L11,
L12,L13,L14,L15,L16,L17,L18,L19,L2
0,L21,L22,L23,L24,L25,L26,L27,L28
145
1IS1-XC6209F332M
SMD voltage regulator IC
XC6209F332MR,SOT-25,-40~85°
1
IC15
146
2LL1-16-3N9SA
Multi-layer chip inductor
SunLord,SDCL1608C3N9STDF,3.9
,nH,±0.3nH,1608
2
L34,L35
147
2LL1-16-10NJA
Multi-layer chip inductor
SunLord,SDCL1608C10NJTDF,10,
nH,±5%,1608
1
L36
