Kirisun DP480 Service Manual

DP480 Service Manual
65
SN
Material NO.
Material Name
Specification
QTY
11
3CR7-SMA-50JF-4
RF coaxial cable
SMA-J, flange, 7200 times of use
1
12
7NRC-4078-01A-N
Antenna connector nut
Brass, black nickel plated, lead free
1
13
7SMF-020040M-SZYB-
N
R M2*4 cross recessed mushroom-
head machine screw
Harden iron, Φ2mm*4mm cross recessed mushroom-head
nickel plated machine screw, metric coarse thread, nylok
8
14
7SMF-020037M-SZCT-
N
Cross recessed countersunk-head
machine screw
Harden iron 1018, Φ2.0mm*3.7mm, nickel plated
2
15
7SMS-025075M-SZYB-
N1
M2.5*7.5 torx round-head machine
screw
Stainless steel, Φ2.5mm*7.5mm, lead free
2
16
7MHC-4072-01A-W
STP knob nut
Brass, inner diameter 6mm, outer diameter 9mm, 2.4mm thick,
lead free
2
17
7MHS-4072-08A-W
STP knob circlip
Stainless steel, T=0.3, original color, lead free
2
18
7STF-019047B-SZHT-X
M1.9*4.7 thick-head self-tapping
Phillips screw
Material: harden iron, Φ1.9mm*4.7mm, flat-head, with guide,
radiant plated
2
19
7MHS-4245-02B-W
DP580 LCD hardware holder
SUS304, 48hr salt spray test passed
1
20
6PD7-4207-HPC
DP586 PTT plate
DP586_PTT_1600707, 0.8mm thick, FR-4, 52X10mm, 2-layer,
lead free
1
21
7MHS-4207-03A-W
DP586 PTT metal dome array
SUS301, Φ5mm, four-point metal dome
1
22
157F01000006
LCD module
Black-and-white screen, 128*64mm, ultra-wide temperature
range, lead free
1
23
7SMF-025080M-SZYB-
Z
M2.5*8 cross round-and-mushroom
headed machine screw
Stainless steel, Φ2.5mm*8mm, black zinc plated, lead free
2
24
3WF7-05030-500C4
FPC cable
Spacing 0.5mm, 40P, length 120mm, 3mm, stiffener 5mm, dual
connectors, single-face, single-direction
1
25
6SS3-MK4237-HMA
DP480 front shell assembly
Cover ultrasonic, black
1
26
63BJ000002
KBJ-17 belt clip (S series)
S760/DP405 belt clip
1
