DP580-01 Digital Two-way Radio
27
(1) Slightly press the top of the belt clip as shown in ①;
(2) Align the battery with the battery installation base at the back and insert the battery as shown in ②.
(3) Slide the battery along the direction as shown in ③ until the battery is fit into the right position.
(4) Slightly press the battery top as shown in ④ until the battery is locked by the latch.
◆Detaching the battery
(1) For detaching the battery, please first turn off the radio.
(2) Slide the battery latch along the direction as shown in ① to bounce the
battery as shown in ②.
(3) Slide to take out the battery along the direction as shown in ③. If there
is belt clip, slightly press the belt clip top as shown in ④ and slide the
battery along the direction as shown in ③ to take out the battery.
Note:
Do not throw the battery terminals with short circuit or battery into fire.
Do not remove the battery case without permission.
