Kirisun DR600 Service Manual

DR600 Service Manual
R286, R288, R289, R146, R147, R148, R149, R164, R165,
R171, R207, R229, R291, R305, R306, R307, R308, R309,
R310, R311, R312, R313, R314, R315, R348, R350, R362, C296
2RS1-16-101J Flake resistor 11
R142, R143, R59, R105, R106, R180, C272, R92, R93, C274,
FB32
2RS1-16-681J
Flake resistor
1
R233
2RS1-16-473J Flake resistor 2 R119, R300
2RS1-16-102J Flake resistor 14
R91, R97, R98, R99, , R137, R156, R157, R158, R159, R219,
R253, R304, R329, R333
2RS1-16-222J Flake resistor 5 R122, R170, R290, R292, R364
2RS1-16-755J Flake resistor 1 R173
2RS1-16-104J Flake resistor 1 R205
2RS1-16-471J
Flake resistor
2
R220, R222
2RS1-10-000O
Flake resistor
4
R260, R51, R96, R41
2RS1-10-330J Flake resistor 26
R64, R73, R74, R75, R76, R78, R79, R101, R102, R108, R36,
R37, R39, R40, R42, R43, R126, R127, R135, R136, , R150,
R151, R152, R153, R154, R155
2RS1-10-101J Flake resistor 3 R103, R104, R111
2RS1-10-472J
Flake resistor
9
R60, R61, R62, R63, R34, R38, R80, R81, R145
2RS1-10-103J Flake resistor 21
R45, R46, R47, R48, R49, R50, R65, R66, R67, R72, R114,
R116, R124, R125, R128, R129, R130, R131, R132, R204, R115
1IS1-TPS54331DDA
Patch switch power IC
1
U1
1IS1-TPS65023
Power management chip
1
U2
1IS1-LM2941S Patch specialized IC 1 U3
1IP1-OMAPL138BZWT3 Dual-core CPU 1 U4
1IM1-MT47H64M16
Patch memerizor IC
1
U6
1IM1-K9GAG08U0M-I Patch memerizor IC 1 U7
1IS1-TPS2051BDGN LDO power voltage regulator IC 1 U8
1IS1-RT9193-33PB Patch voltage regulator IC 1 U12
1IS1-RT8008GB
Patch voltage transformer IC
1
U13
100
