Kirisun DR600 Service Manual

DR600 Service Manual
1IS1-EP4CE30F23I7N
Patch specialized IC
1
U14
1IS1-RT9193-25PB Patch voltage regulator IC 1 U15
1IS1-DP83848I Patch specialized IC 1 U17
1DR1-TPD4S012DRY TVS diode 1 U19
1IS1-ADS1015
AD transformer IC
1
U22
1IS1-TLV5614 DA transformer chip 2 U24, U27
1IS1-LM4040B20IDBZT Patch voltage regulator IC 1 U29
1IS1-TLV320AIC14 CODEC chip 1 U30
1IS1-TDA8541T
Audio power amplifier IC
1
U31
1IS1-MAX3232ESE
Patch dual-channelRS-232 wire
driver/receiver IC
1 U32
1IL1-AD8031ARTZ
Patch linear IC
1
U38
1IM1-AT24C08CN-SH memorizer IC 1 U23
1IS1-XC6209F302PR Patch voltage stabilization IC 1 U20
1IS1-XC6209F332PR Patch voltage stabilization IC 1 U5
1IS1-XC6209F502PR
Patch voltage stabilization IC
1
U26
5XT1-MC146-32R76K Patch ceramic harmonic oscillator 1 Y1
5OC1-24R0-MML-3225 crystal oscillator 1 Y2
5OC1-50R0-MML-3225 crystal oscillator 1 Y3
5XC1-18R4-CEC5032SC
H
Patch crystal oscillator 1 Y4
1TF1-ST2301 Patch FET 2 Q7, Q11
5OD1-12R8-AL3-3225
Pressure temperature compensated crystal
oscillator
1 Y5
1MR3-MAX-6Q GPS module 1 U9
2RE1-16-1801
Patch precision resistor
1
R365
2CC1-32-Y5V160-106Z
Flake multi-layer capacitor
2
C243, C237
2CC1-16-C0G500-7R0C Flake multi-layer capacitor 2 C310, C328
2CC1-16-C0G500-9R0C Flake multi-layer capacitor 2 C311, C445
2CC1-16-C0G500-150J Flake multi-layer capacitor 2 C312, C329
101
