Kirisun DR600 Service Manual

DR600 Service Manual
2CC1-16-C0G500-240J
Flake multi-layer capacitor
2
C314, C446
2CC1-16-C0G500-390J Flake multi-layer capacitor 2 C313, C330
2CC1-16-C0G500-820J Flake multi-layer capacitor 3 C301, C303, C307
2CC1-16-C0G500-121J Flake multi-layer capacitor 1 C308
2CC1-16-C0G500-151J
Flake multi-layer capacitor
1
C305
2RS1-16-301J Flake resistor 1 R144
3SE1-SDIP-04 Patch DIP 1 J4
6PM7-4071-HBC Repeater baseband board PCB 1
Table 8 Parts List (Front Panel)
Part No. Acccessory Names Quantity Location
3CB3-A2548WV-2X05P Plug-in Board-to-board connector 1 J1
4PE3-0705-F4 Plug-in unit LED 8 LED1, LED2, LED3, LED4, LED5, LED6, LED7, LED9
4PE3-0705-F2 Plug-in unit LED 1 LED8
2CC1-16-Y5V500-104Z
Flake multi-layer capacitor
1
C1
5FE1-BLM18PG181SN1 Patch EMI suppression filter 1 FB1
1TT1-DTC114YE Patch triode 8 Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8
2RS1-16-330J
Flake resistor
8
R1, R2, R3, R4, R5, R6, R7, R8
2RS1-16-102J
Flake resistor
1
R16
2RS1-16-101J Flake resistor 8 R9, R10, R11, R12, R13, R14, R15, R17
6PD7-4071-HFB Repeater PCB 1
102

Kirisun DR600 Specifications

General

Brand	Kirisun
Model	DR600
Category	Repeater
Language	English
