DR600 Service Manual
3WPD-S4071-E2
Power cable 5, 590mm in length, 18AWG,3.96, with
connector, round terminals and fuse box, Mingxin brand
30-36
3WPD-S4224-F1 Power cable 6, 2-
pin, 130mm in length, 20AWG, one
round terminal and one peeled tin-dipped terminal
4-36
3WPD-S4224-G1 Power cable 7, 2-
pin, 220mm in length, 20AWG, one end
with a connector of 2.54mm spacing, the other end
peeled tin-dipped
5-35
3WPT-P26073PH25420P Dual-
connector FFC 1, AWG26#, 2.54mm spacing,
dual-row, 73mm in length, 20P dual-head socket, reverse
outwards, Mingxin brand
16-26
3WPT-P260103PH25426
P
Dual-
connector FFC 5, AWG26#, 2.54mm spacing,
dual-row, 103mm in length, 26P dual-
head socket,
reverse inwards, Mingxin brand
18-28
3WPT-P26450PH25410P Dual-con
nector FFC 3, AWG26#, 2.54mm spacing,
dual-row, 410mm in length, 10P header, dual-head
socket, reverse-direction and reverse-edge wiring
2-29
3WPT-P26330PH25410P Dual-
connector FFC 4, AWG26#, 2.54mm spacing,
dual-row, 330mm in length, 10P header, one end without
header connector, same-direction and reverse-edge
wiring
15-24
3WPT-P26175PH25426P Three-
connector FFC 1 (Mingxin brand), AWG26#,
2.54mm spacing, three-
low, 175mm in length,
reverse-direction and reverse-edge wiring for 26P socket
and 10P header
9-21, 22
4MF7-DFB402012H-2
Dual parallel fans, DFB402012H, 12V, 40x40x20, 370mm
in length, with a connector
1-23
4MF7-DFB402012H-1 Fan, DFB402012H, 12V, 40x40x20, with round terminals 3-37
3WPD-160165-1PIN Grounding wire, 1-pin, yellow-green, 165mm in length,
16AWG, two round terminals, Mingxin brand
31-case
3CR7-SMA-220
RF coaxial line 4, SMA to SMA, line type: 1.13mm
micro-coaxial cable, line length: 220mm
10-25
39
