Kirisun DR600 Service Manual

DR600 Service Manual
1K
capacitor
2CC1-16-C0G500-15
0J
R flake multi-layer
capacitor
1608, 15P±5%, 50V, C0G 3 C3064, C3107, C3072
2CC1-16-X7R500-18
2K
R flake multi-layer
capacitor
1608, 1800P±10%, 50V, X7R 1 C3077
2CC1-16-C0G500-16
0J
R flake multi-layer
capacitor
1608, 16P±5%, 50V, C0G 1 C3080
2RE1-16-3301
Precision resistor
1608, 3.3K±1%
2
R3029, C3083
2CC1-16-X7R500-15
2K
flake multi-layer
capacitor
1608, 1500P±10%, 50V, X7R 1 C3085
2CC1-16-Y5V500-10
4Z
flake multi-layer
capacitor
1608, 0.1μF+80%/-20%, 50V, Y5V,
replaced no: 2CC1-16-Y5V250-104Z
9
C4004, C4015, C4018, C4023, C4030,
C4031, C4046, C4055, C4058
2CC1-16-C0G500-56
0J
R flake multi-layer
capacitor
1608, 56P±5%, 50V, C0G 3 C4006, C4016, C3059
2CC1-16-C0G500-27
0J
R flake multi-layer
capacitor
1608, 27P±5%, 50V, C0G 1 C4019
2CC1-16-C0G500-18
1J
flake multi-layer
capacitor
1608, 180P±5%, 50V, C0G 1 C4020
2CE1-VS250-101M0
607D
Aluminum electrolytic
capacitor
SMD-6.3x7.7mm, 100uF/25V 1 C5003
2CT1-TS32-100-220
M
Tantalum capacitor 3216, 22μF±20%, 10V, TSn series (level A) 2 C5005, C6007
2CC1-16-Y5V250-10
5Z
flake multi-layer
capacitor
1608, 1μF+80%/-20%, 25V, Y5V 3 R6004, C6014, C6015
1DS1-DA2S10100L R switch diode DA2S10100L 2 D1000, D1001
1DV1-HVC376B
R varactor (production
halt)
HVC376B(B9) 26
D3001, D3002, D3003, D3004, D3005,
D3006, D3007, D3008, D3009, D3010,
D3011, D3012, D3013, D3014, D3015,
D3016, D3017, D3018, D3019, D3020,
D3021, D3022, D3023, D3024, D4000,
54
