Kirisun DR600 Service Manual

DR600 Service Manual
0J
capacitor
2CC1-16-C0G500-30
0J
R flake multi-layer
capacitor
1608, 30P±5%, 50V, C0G 2 C1095, C1096
2CC1-16-C0G500-1R
0B
flake multi-layer
capacitor
1608, 1P±0.1P, 50V, C0G 10
C1101, C1103, C1116, C1117, C6020,
C6026, C6036, C6041, C6057, C6063
2CC1-16-C0G500-39
0J
R flake multi-layer
capacitor
1608, 39P±5%, 50V, C0G 2 C1102, C1118
2CC1-16-C0G500-82
0J
R flake multi-layer
capacitor
1608, 82P±5%, 50V, C0G 2 C2020, C2026
2CC1-16-C0G500-12
1J
R flake multi-layer
capacitor
1608, 120P±5%, 50V, C0G 2 C2021, C2023
2CC1-16-C0G500-62
0J
flake multi-layer
capacitor
1608, 62P±5%, 50V, C0G 2 C2022, C2025
2CC1-16-C0G500-12
0J
R flake multi-layer
capacitor
1608, 12P±5%, 50V, C0G 4 C2031, C3106, C1114, C1115
2CC1-16-C0G500-3R
5C
R flake multi-layer
capacitor
1608, 3.5P/3.6±0.25P, 50V, C0G 2 C3020, C1110
2CC1-16-C0G500-1R
5B
flake multi-layer
capacitor
1608, 1.5P±0.1P, 50V, C0G 1 C1109
2CC1-16-C0G500-2R
0B
flake multi-layer
capacitor
1608, 2P±0.1P, 50V, C0G 4 C2019, C3001, C3026, C3060
2RS1-16-000O
R flake multi-layer
capacitor
1608, 0Ω 17
R1017, R1018, R1029, R2010, L2012,
C3012, L3015, R3027, R3028, R3031,
R3038, R3042, R4003, R6012, R6013,
R6040, R6041
2CC1-16-C0G500-22
0J
R flake multi-layer
capacitor
1608, 22P±5%, 50V, C0G 1 C3050
2CC1-16-C0G500-22
1J
R flake multi-layer
capacitor
1608, 220P±5%, 50V, C0G 4 C3052, C3057, C3084, C3088
2CC1-16-X7R500-33 flake multi-layer 1608, 330P±10%, 50V, X7R 5 C3054, C3068, C3108, C3114, C3115
53
