Kirisun DR600 Service Manual

DR600 Service Manual
2CT1-TS32-350-R33
M
R tantalum capacitor 3216, 0.33μF±20%, 35V, TS series (level A) 1 C1070
2CC1-16-X7R500-10
2K
R flake multi-layer
capacitor
1608, 1000P±10%, 50V, X7R 21
C1072, C1092, C1093, C1097, C3033,
C3034, C3035, C3036, C3037, C3038,
C3044, C3073, C3075, C3093, C3099,
C3102, C6001, C6003, C6010, C6012,
C3076
2CT1-TS32-100-2R2
M
R tantalum capacitor 3216, 2.2μF±20%, 10V, TS series (level A) 1 C1075
2CC1-16-C0G500-4R
0B
flake multi-layer
capacitor
1608, 4P±0.1P, 50V, C0G 4 C3000, C3005, C3006, C3019
2CC1-16-C0G500-8R
0C
R flake multi-layer
capacitor
1608, 8P±0.25P, 50V, C0G 4 C1079, C1108, C1068, C4007
2CC1-16-C0G500-47
0J
R flake multi-layer
capacitor
1608, 47P±5%, 50V, C0G 49
C1084, C1099, C2024, C3007, C3008,
C3009, C3039, C4011, C6021, C6022,
C6023, C6024, C6025, C6027, C6028,
C6029, C6030, C6031, C6032, C6033,
C6034, C6035, C6037, C6038, C6039,
C6040, C6042, C6043, C6044, C6045,
C6046, C6047, C6048, C6049, C6050,
C6051, C6052, C6053, C6054, C6055,
C6056, C6058, C4013, C6059, C6060,
C6061, C6062, C6064, C6065
2CC1-16-C0G500-10
0D
R flake multi-layer
capacitor
1608, 10P±0.5P, 50V, C0G 3 C1085, C1086, C1100
2CC1-16-X7R500-27
1K
R flake multi-layer
capacitor
1608, 270P±10%, 50V, X7R 2 C1087, C1088
2CC1-16-C0G500-68
0J
R flake multi-layer
capacitor
1608, 68P±5%, 50V, C0G 3 C1091, C3056, C4053
2CC1-16-C0G500-18 R flake multi-layer 1608, 18P±5%, 50V, C0G 2 C1094, C3104
52
