DR600 Service Manual
C4038, C4039, C4041, C4044, C4048,
C4051, C4056, C4059, C4060, C4061
2CC1-16-X7R500-10
3K
R flake multi-layer
capacitor
1608, 10nF±10%, 50V, X7R 57
C1002, C1003, C1016, C1017, C1022,
C1023, C1027, C1028, C1036, C1038,
C1040, C1041, C1043, C1045, C1047,
C1048, C1050, C1052, C1080, C1082,
C3028, C3032, C3043, C3048, C3053,
C3078, C3096, C3098, C3111, C4000,
C4001, C4002, C4003, C4005, C4008,
C4012, C4014, C4017, C4026, C4027,
C4032, C4033, C4042, C4043, C4049,
C4050, C4054, C4057, C5000, C5001,
C5002, C5004, C5006, C5007, C5008,
2CC1-16-C0G500-47
1J
R flake multi-layer
capacitor
1608, 470P±5%, 50V, C0G 11
C3070, C1006, C1007, C1008, C1012,
C1032, C1033, C1067, C1089, C1090,
R3037
2CT1-TS32-6R3-150
M
R tantalum capacitor 3216, 15μF±20%, 6.3V, TS series (level A)) 3 C1009, C1011, C1013
2CC1-16-C0G500-6R
R flake multi-layer
1608, 6P±0.25P , 50V, C0G 7
C1054, C1055, C2030, C2032, C3023,
2CC1-16-C0G500-5R
0B
flake multi-layer
capacitor
1608, 5P±0.1P, 50V, C0G 11
C4062, C1060, C1061, C1062, C1076,
C1111, C3010, C3011, C3013, C3014,
C3015
2CC1-16-Y5V160-10
4Z
flake multi-layer
capacitor
1608, 100nF+80%/-20%, 16V, Y5V 25
C1065, C1078, C1081, C1083, C1106,
C1113, C2009, C2011, C2013, C2014,
C2038, C3041, C3045, C3049, C3055,
C3071, C3079, C3081, C3086, C3087,
C3089, C3090, C3092, C3101, C3103
M
R tantalum capacitor 3216, 0.1μF±20%, 35V, TS series (level A) 3 C1069, C3100, C1071
51
