Appendix 1 Band Spare Part List
Table 1 400-470 Parts List (Rx Module Section)
Part No. Accessory Name Description Quantity Location
6PM7-4067-HRB DR650-02 Rx board
DR650-02-RX-130304.PCB, 4 layers, 1.6MM
thickness, 194X90mm, FR-4, no frequency
distinction
1
3FW1-42932-302320
R fuse
429003/433003/466003, 3216, 3A/32V
1
CB5000
5FT1-LTWC450G E ceramic filter LTWC450G 1 CF3000
5FT1-LTWC450H
E ceramic filter 7200
7200EX 5200 6500,
6800, 7800, helmet
LTWC450H 1 CF3001
2CT1-TS32-160-100
M
R tantalum capacitor 3216, 10μF±20%, 16V, TS series (level A) 28
C1000, C1005, C1014, C1019, C1020,
C1025, C1030, C1031, C1057, C1058,
C4024, C4029, C4040, C4045, C4047,
C4052, C6002, C6008, C6011, C3029,
C3030, C3046, C3067, C3094, C3097,
C3109, C3112, C3113
2CC1-16-C0G500-10
1J
R flake multi-layer
capacitor
1608, 100P±5%, 50V, C0G 60
C1001, C1004, C1010, C1015, C1018,
C1021, C1024, C1026, C1029, C1034,
C1035, C1037, C1039, C1042, C1044,
C1046, C1049, C1051, C1053, C1056,
C1059, C1063, C1064, C1104, C1105,
C1112, C1119, C2008, C2010, C2012,
C2017, C3003, C3004, C3027, C3031,
C3040, C3042, C3047, C3082, C3091,
C3095, C3110, C4021, C4022, C4025,
C4028, C4034, C4035, C4036, C4037,
50
