Kirisun DR600 Service Manual

DR600 Service Manual
2LW1-16UC-R33G Patch winding conductor 1608, 330nH±2%(C1608BR33G), pb-free 10
L1005,L1006,L1011,L1015,L1023,L102
4,L1026,L1027,L1028,L1030
2LL1-16-R82K Laminated conductor 1608, 0.82uH±10%(MLF1608DR82K TA00) 2 L1007,L1029
2LL1-16-1R0K
R Laminated conductor
1608, 1μH±10%(MLF1608A1R0K)
2
L1025,L3013
2LW1-20UC-102J Patch winding conductor
2012, 1μH±5%, ceramic core
(C2012C-1R0J)
3 L2004, L3007, L3024
2LW1-16UC-120G Patch winding conductor
1608, 12nH±2%, ceramic core
(C1608CB-12NG)
1 L2006
2LW1-20UC-180J
R patch winding
conductor
2012, 18nH±5%, ceramic core
(C2012C-18NJ)
2 L2009, L2010
2RS1-20-000O R flake resistor 2012, 0Ω 4 L2011, L2013, L3003, L3004
2LH1-R401R5-R03-0
5
R patch air core inductor
Wire diameter φ0.40, internal diameter φ1.5,
3 circles, pin height 0.5ml
2 L3000, L3002
2LH1-R401R5-R04-0
5
R patch air core inductor
Wire diameter φ0.40, internal diameterφ1.5,
4 circles, pin height 0.5mm
7
L3001, L3006, L3008, L3009, L3010,
L3011, L3012
2LW1-25UC-103J R patch winding inductor
2520, 10μH±5%, ceramic core
(FLM2520-100J)
4 L3005, L4002, L4003, L1022
2LW1-16UC-271G patch winding inductor
1608, 270nH±2%, ceramic core
(C1608CB-R27G-RF)
2 L3016, L3021
2RS1-16-271J R flake resistor 1608, 270Ω±5% 1 L3018
2LL1-16-R56K R laminated inductor 1608, 560nH±10%(MLF1608DR56K) 2 L3022, L3023
2LW1-20UC-331J patch winding inductor
2012, 330nH±5%, ceramic core (high
frequency)
3 L4001, L1019, L1020
2LL1-16-3R3K R laminated inductor 1608, 3.3μH±10%(MLF1608A3R3K TA00) 1 L4004
2LW1-25UC-332K patch winding inductor
2520, 3.3μH±10%, ceramic core
(NL252018T-3R3K/NLV25T-3R3K)
1 L4005
5FE1-BLM21P300S
R patch EMIsuppression
filter
2012,
BLM21P300S/BLM21PG300S(0149-05)
1 L5000
1IS1-XC6209F302PR
Patch voltage
stabilization IC
XC6209F302PR, SOT-89-5, 3.0V stable
voltage
2 Q1000, Q4002
56

Kirisun DR600 Specifications

General

Brand	Kirisun
Model	DR600
Category	Repeater
Language	English
