Kirisun DR600 Service Manual

DR600 Service Manual
1TT1-2SC4617-R
R patch triode
2SC4617-R(BR), EMT3
2
Q1001, Q1005
1IS1-XC6209F502PR
Patch voltage
stabilization IC
XC6209F502PR, SOT-89-5, 5.0V stable
voltage
6
Q1002, Q1004, Q3000, Q3003, Q3005,
Q4003
1IS1-XC6209F332PR
Patch voltage
stabilization IC
XC6209F332PR, SOT-89-5, 3.3V stable
voltage
3 Q1003, Q1006, Q4004
1TT1-2SC5006 patch triode 2SC5006 1 Q1007
1TF1-2SJ243
R patch FET
2SJ243-SMD
2
Q1008, Q1010
1TT1-2SC3356-R24 R patch triode 2SC3356-R24, SOT23, NPN 7
Q1009, Q1011, Q2002, Q3001, Q3002,
Q3004, Q4000
1TT1-DTC114YE patch triode Digital triode DTC114YE-SMD 2 Q4001, Q5000
2RS1-16-472J R flake resistor 1608, 4.7K±5% 8
R3033, R1006, R3021, R1000, R1001,
R3019, R3044, R3047
2RS1-16-392J R flake resistor 1608, 3.9K±5% 3 R1002, R1015, R3043
2RS1-16-682J R flake resistor 1608, 6.8K±5% 2 R1003, R1043
2RS1-16-680J R flake resistor 1608, 68Ω±5% 2 R1004, R1044
2RE1-16-1200
Patch precision resistor
1608, 120Ω±1%
5
C4009, C4010, R1021, R1005, R1025
2RS1-16-103J R flake resistor 1608, 10K±5% 19
R6007, R6009, R1007, R1011, R1030,
R1031, R1032, R1033, R1034, R1035,
R1036, R1037, R1039, R1040, R1041,
R3017, R4002, R4007, R4008
2RE1-16-1000 Patch precision resistor 1608, 100Ω±1% 11
R3002, R3003, R1020, R1008, R1009,
R1010, R1013, R1014, R1016, R1022,
R1024
2RE1-16-47R0 Patch precision resistor 1608, 47Ω±1% 1 R1019
2RS1-16-102J R flake resistor 1608, 1K±5% 7
R1023, R1028, R1042, R3018, R3036,
R4004, R4009
57
